Alco-Sensor® VXL with Printer

The Alco-Sensor® VXL is available with a docking station and thermal printer. The Alco-Sensor® VXL is programmed to prompt the operator through a step-by-step test sequence that produces a displayed, printed and stored to memory test record.The instrument can be programmed to support a variety of different test protocols. Off the shelf programs include workplace protocols (U.S. DOT, DOE, NRC and non-regulated testing) and basic law enforcement protocols. Customized jurisdictional applications are available upon request.

ApprovalsNHTSAListed on the Conforming Products List for Evidential Breath Measurement Devices.
Analytical SystemElectrochemical Sensor

(Fuel Cell)

Select sensor, manufactured to Intoximeters exacting specifications for accuracy, repeatability and long life.
Measurement Range0.000 to 0.440 g/210LThe off the shelf instrument is designed to offer a range of results that our customers commonly encounter when performing breath alcohol testing.  The instrument is capable (with custom software setup) of performing analysis when even the most extreme blood alcohol levels found in living humans are encountered.  As well, custom software setup allows the instrument to report results in most units of measure used in breath alcohol testing around the world.
Accuracy and PrecisionHighly accurate and precise evidential grade resultsIntoximeters fuel cell based instruments set the industry standard for accuracy and precision.  These precise and linear devices offer consistent output that results in evidentiary grade analysis.
Sensor SelectivityHighly specific for alcoholFuel Cell sensors are sought after for their specificity to alcohol.
Sampling MethodFlow, Volume, Breath DropInstruments running the standard software require a consistent flow, a minimum volume and then a drop in flow before sampling a deep lung breath.  Alternate sample capture algorithms are available in customized programs.
Testing EnvironmentInstrument TemperatureThe temperature of the instrument must be at, or between, 0 and 50 degrees C.
Ambient TemperatureAs long as the instrument is at temperature, the instrument can be used at, or between, ambient temperatures of -20  to 70 degrees C.
Humidity10% to 100% relative humidity  (The instrument is not designed to be used under water.)
Ambient Pressure600 mbar to 1400 mbar; 450 mmHg [0 °C] to 1050 in mmHg [0 °C]
MouthpieceStyleOne-way check valve
InstallationLever and set in the lighted mouthpiece guide
Visual OutputDisplayMulti-color backlit graphic LCD
LEDSide viewable LED indicates blow condition and warnings.
Audio OutputBeeperAudible tone to support graphical messaging system.
Data StorageNumber of TestsMore than 7,000 test memory for a basic test record.
Power OptionsDisposable Battery4 x 1.5 V AA alkaline batteries
Rechargeable Battery4 x AA NiMH rechargeable cells
Wall PowerPower module – unlimited # of tests
Case ConstructionABSRugged casing with rubber over-molding protects instrument and internal components.
Size, Shape and WeightDimensions7.5” x 4.0” x 2.25”
Weight12 oz  (343 grams)
Measurement TypesAutomatic Direct BreathAuto sampling of subjects’ deep lung breath samples.
Manual Direct BreathManual sampling option for subjects who cannot meet the minimum flow and volume requirements of the instrument.
Passive TestingManual or Automatic sampling capabilities for passive alcohol detection.
Headspace SamplingCapable of measuring the headspace over a liquid to determine if alcohol might be present in the solution.
SecurityPasswordConfigurable software allows password protection as an option.
OptionsBarometerThe optional on-board barometer offers a simple way to determine the most accurate dry gas accuracy checks and calibrations.
BluetoothThe optional on-board Bluetooth option offers wireless communication capabilities.
PrintersSerial thermal printer interface to the ASVXL.
SoftwareAlco-Sensor V Accelerator
